Product Name: Two-way Cartridge Valves
1. Compact hydraulic system, easy installation and short assembly period
2. OEM acceptable, according to customer's requirements
3. If the hydraulic system changes, change the working conditions need to change components, the assembly easily and quickly
4. Hydraulic tube-free connection between devices, eliminating for tubing, pipe joints and other leakage, caused by vibration and noise
5. The hydraulic system configuration flexibility, neat appearance, maintenance is easy
6. A standardized, generic and high level of integration
7. Manifold block is made of hydraulic valves and valves body.
8. It make adjustment for direction of hydraulic oil, pressure, flow regulation
9. Manifold block features light weight, small resistance, impact and low cost
10. Manifold block is composed of integrated hydraulic components (such as threaded cartridge valves, stack valves)
11. If use integrated hydraulic components for hydraulic system, no need extra connection block, but use directly its own body as a composite body
12. Role of manifold block depend on which hydraulic components are included. Different hydraulic components have different functions. If relief valve, throttle valve and directional valve are included in the manifold block, so it functions pressure regulation, speed adjustment and direction change.
13. Material: Aluminum or steel
14. Very competitive price
|
Product material |
45# carbon steel |
|
Piston rod diameter |
30-320mm |
|
Bore diamater |
60-400mm |
|
Stroke length |
4000mm |
|
Working pressure |
16mpa |
|
Testing pressure |
24mpa |
|
Oil fluid |
Mineral oil to DIN 51 524 |
|
Fluid temprange |
Minus -20°to 70° |
|
Mounting style |
As customer's requirement |
|
Stroke and tolerance |
|
Nominal stroke(mm) |
Dimension tolerance(mm) |
|
0-499 |
±1.5 |
|
500-1249 |
±2 |
|
1250-3149 |
±3 |
|
3150-8000 |
±5 |
Catsu hydraulic is a leading cylinder manufacturer in China, we are the member of China Hydraulic Industry association and Engineering Machinery Association. We specialize in the design, manufacture super large & long, high requirements & high anticorrosion hydraulic cylinder, spillway(dam) radial gate hydrauli c cylinder, Servo hydraulic cylinder, cylinders Including marine & offshore, Offshore Oil & Gas equipments, Smelters(steel factory), metallurgy, mining, engineering machinery equipment, water conservancy facilities, pressure machines, manifold blocks and hydraulic power system units.
After years of developing, our company start from a small workshop, right now we have become a large and famous hydraulic cylinder manufacturer, we have over 65000 square meters modern standard factory, have more than 270 sets of modern big digital equipments, such as ball rolling machines, honing machines, CNC, Boring machine, lathe, cutting machine, welding machine, auto welding robot, shot blast room, paiting roon and so on.
The rod we can plate hard chrome, nickel or Ceramic coating. The seals we import from the famous brands: NOK, Hallite, Merkel
Our Capacity: Maximal bore: 2000mm, Maximal Stroke: 20meters, maximal weight: 110 ton/PC, maximal pressure can up to 160Mpa.
Honest, Innovation, High quality, competitive price are our core purpose, once cooperation, friend forever. Friends and customers are welcome to our facility anytime.
We make the Hydraulic World!
