Air Conditioner Motorized Ball Valve with Actuator 24V (DF/F-02)
| Price: |
US $ 10.54-11.5/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
| Prod Model: |
DF/F-02 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
for Air Conditioner |
| Cooling Method: |
Indirect Cooling |
| Quality Standar: |
Good |
| Price: |
Cheap |
| MOQ: |
10PCS |
| Free Samples: |
Yes |
| Connection Form: |
Thread |
| Channel: |
Straight Through Type |
| Structure: |
Fixed Ball Valve |
| Type: |
Fixed Ball Valve |
| Material: |
Brass |
| Application: |
Household Usage |
Product Description
DF/F Series Motor Valve is available for central air-conditioner system and opening/closing of the heating system pipe to control the temperature. The control valve is driven by the one-way magnetic sync motor. The valve is normal close when it doesn't work. When it starts to work, the thermostat provides a signal to make the motor valve work. After the valve opens, the cold or hot water will enter the fan coil to provide the cold or hot air for the room. When the room temperature reach to the setting, the thermostat will cut off the motor valves current and the return spring will close the valve to prevent the water from entering the fan coil. The room temperature can be kept that was set by thermostat by opening/closing the valve.
The driver of DF/F series motor valve is connected with the valve by the coupling. After the valve is installed, then the driver can be installed.
| Model | Valve Type | Connection | Flow Factor | Working Medium | Medium Temperature | Ambient Temperature | Bearing Pressure | Voltage |
| DF/F-02-215 | two way | G1/2" | 2.5Kv | Cold water
/Heat water | 2~94º C | 0~65º C | 2.5Mpa | 220V/ 50-60HZ |
| DF/F-02-315 | three way | G1/2" | 2.5Kv |
| DF/F-02-220 | two way | G3/4" | 3.5Kv |
| DF/F-02-320 | three way | G3/4" | 3.5Kv |
| DF/F-02-225 | two way | G1" | 4.0Kv |
| DF/F-02-325 | three way | G1" | 4.0Kv |
