| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
2" to 8" |
| Material: |
Cast Steel |
| Application: |
Household Usage |
| Connection Form: |
Lift Disc |
| Structure: |
Lift Disc |
| Function: |
Check Valve |
Product Description
Cast Steel Lift Disc Check Valve - Product Features:
PRODUCT RANGE
Class 150 from 2" to 8"
Class 300 from 2" to 8"
MATERIALS
BODY: Carbon steel, Stainless steel, Low temperature carbon steel, Duplex, Special Alloys, ...Other materials under request
TECHNICAL SPECIFICATION
Design and Manufacture: BS 1868 or API 6D
Inspection and Test: API 598 or API 6D
End flange dimension: ASME B16.5, ASME B16.47A, API B16.47 MSS SP-44
BW end dimension: ASME B16.25
Face to face and end to end: ASME B16.10
Pressure-temperature: ASME B16.34
Wall thickness dimension: API600 and BS1868
APPLICATION
Refinery
Chemical
Petrochemical
APPLICATION Power plant
Gas
CERTIFICATES
SBDM is one of high-tech manufacturer of valves and oil purifier machine, including R&D, manufacturing, sales and service.
We manufacture API6D BALL VALVE, API600 GATE VALVE, BS1868 CHECK VALVE AND BS1873 GLOBE VALVE. We also provide high quality oil purifier machine.
