| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Class: |
150lb,Pn10,Pn16 |
| Size: |
2"-48" |
| Actuator: |
Pneumatic, Electric |
| Connection Form: |
Flange |
| Structure: |
Centre Sealing |
| Seal Form: |
Force Sealed |
| Work Pressure: |
Low Pressure (',Pn<1.6mpa) |
| Working Temperature: |
Normal Temperature (',-40??C
|
| Material Of Seal Surface: |
Soft Sealed |
| Application: |
Industrial Usage |
Product Description
Pneumatic actuator control flanged butterfly valve
Materials:
Body: GGG40.GGG50,WCB,etc.
Disc: GGG40,GGG50,WCB,SS304,SS316 with Spraying Nylon.
Stem: Stainless steel 420.SS416,SS316,SS314,A654 Gr630 etc
Seat: EPDM
Type Available: Flanged
Sizes Available: 2"-48"
Pressure: 150LB/ Mpa (1.0, 1.6, 2.0, 2.5)
Basic Design: ANSI/API609
Face to Face Dimension: BS5155 Short, ISO5752 (Series 13)
Inspection & Testing: API 598,
Flanged End Dimension: ANSI B16.1
Suitable Mediums: Fresh water, sea water, gas, oils, acids, alkalis, etc
Suitable Temperature: -26-135C degree for EPDM
EXXON mainly offers resilient seated and AWWA butterfly valves. Valves size from 2" to 48", and connection ways can be lugged or semi-lugged wafer style, double flanged style, single flanged style, etc. Working pressures range can be from 150 to 250 PSIG. Body materials can be cast iron, ductile iron, stainless steel, WCB, etc, and the dis materials can be ductile iron (nickel coated cast iron and Nylon coated cast iron are available). Valve seat materials consist of neoprene, silicone, hypalon, Viton, Buna N, and EPDM.
Series of butterfly valve:
Wafer Valves
Full Lug Valves
Double Flanged Valves
Mono Flanged Valves
Teflon Lined Valves
Tianjin Exxon Valve Co., Ltd. Offers several styles of Rubber Lined Concentric Butterfly Valves, Resilient Seated Gate Valves and Soft Seated Dual Plate Check Valves to meet your requirements. We would like to help you choose the correct valve style according to the process conditions and system needs of the valves.
Our company has a comprehensive computer-aided design systems and sophisticated computer numerically equipment in production, processing and testing. We are strictly according to the international quality system standard ISO9001 for production.
We specialize in soft sealed butterfly valves and gate valves of wafer type, flange type and groove type, which are widely applied in petroleum, chemical, natural gas, food, water supply and other industrial areas.
The valves of EXXON are highly appreciated at home and abroad. Even though there is a fierce competition in the market nowadays, EXXON obtains a steady and efficient development being guided by our manage principle, that is, guided by the science & technology, guaranteed by the quality, adhere to sincerity and target at excellent service...
We persist in the pursuit of excellence, strive to build EXXON brand. Great effort will be made to achieve common progress and development with all of you and creating a better future.
Tianjin Exxon Valve Co., Ltd. Offers several styles of Rubber Lined Concentric Butterfly Valves, Resilient Seated Gate Valves and Soft Seated Dual Plate Check Valves to meet your requirements. We would like to help you choose the correct valve style according to the process conditions and system needs of the valves.
Our company has a comprehensive computer-aided design systems and sophisticated computer numerically equipment in production, processing and testing. We are strictly according to the international quality system standard ISO9001 for production.
We specialize in soft sealed butterfly valves and gate valves of wafer type, flange type and groove type, which are widely applied in petroleum, chemical, natural gas, food, water supply and other industrial areas.
The valves of EXXON are highly appreciated at home and abroad. Even though there is a fierce competition in the market nowadays, EXXON obtains a steady and efficient development being guided by our manage principle, that is, guided by the science & technology, guaranteed by the quality, adhere to sincerity and target at excellent service...
We persist in the pursuit of excellence, strive to build EXXON brand. Great effort will be made to achieve common progress and development with all of you and creating a better future.
