| Prod Model: |
Q347F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Design Standard: |
API 6D |
| Face To Face Dimension: |
ANSI B 16.10 / API 6D |
| Size: |
2" to 48" |
| Materials: |
Forged Steel A105, F316, Lf2 |
| Test Standard: |
API 598 |
| End Flange Dimension: |
ANSI B 16.5 |
| Pressure Rating: |
Class 150lb, 300lb, 600lb, 900lb, 1500lb |
| Connection Type: |
Flanged End RF |
| Connection Form: |
Flange |
| Channel: |
Straight Through Type |
| Type: |
Fixed Ball Valve |
| Application: |
Household Usage |
| Material: |
Forged Steel A105, F316, Lf2 |
| Driving Mode: |
Maual, Gear, Electrical, Pneumatic |
| Structure: |
Trunnion Mounted Ball Valve |
| Function: |
Ball Valve |
Product Description
Forged Steel Trunnion Mounted Ball Valve - Product Features:
CLASS 150~1500 FORGED STEEL TRUNNION BALL VALVE
Bolted cover or welded cover,three-piece Body,fixed Ball
Full or Reduced bore,Blowout Proof Stem
Fire safe and Anti static
Dual seat with injection and drain & outlet
ASTM A105N,A182 F304,A182 F316,A182 F304L,A182 F316L
Standards compliance
Design and manufacture: ANSI B16.34,API 608,API 6D,BS5351
Face to face dimensions: ANSI B16.10,API 6D
Flanged connection: ANSI B16.5
Butt welded: ANSI B16.25
Fie-safe: API 607,API 6FA
Test and inspection: API 598,API6D
Chaote valve is a professional development, production and sale valves manufacture.
Professional stainless steel\alloy steel\carbon stell variety of materials such as all kinds of industrial valves.
Chaote has acquired API 6D and CE certification as well as the quality management system ISO9001. We get "famous brand of China"and"Quality AAA manufacture"honor.
We main professional production ANSI/API, JIS, DIN, GB/JB standard ball and plug series valves.
Chaote has developed 2bases for manufacturein Wenzhou and Lishui, Which totally convers 26, 667.00 square meters. There are over 365 staff(including 20 technical staff),
Over 100 sets of large and medium sized equipments(including numerical control machines)and over 60 sets of inspection and testing equipments. The products has unique designs,
Exquisite workmanship and ispection by sophisticated methods.
The main products are industrial conforming to American standard, including ball valve, gate valve, globe valve, check valve, butterfly valve and plug valve totally of over 50 series and more than
1500 kinds of products. The annual production capacity is over 15 thousand tons.
We are looking for international partners, We provide the superior quality products, favorable price and Professional after-sales service.
Welcome to contact us!
