| Prod Model: |
KR01-HC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
1/4''-3'' |
| Connection Form: |
Thread |
| Channel: |
Straight Through Type |
| Structure: |
Floating Ball Valve |
| Type: |
Floating Ball Valve |
| Material: |
Stainless Steel |
| Application: |
Industrial Usage |
Product Description
SIZE:1/4"~3"
REDUCED BORE (1000/2000 PSI)
Threaded: BSP. NPT. PT. DIN 259, 2999
Thread Acc: ANSI B1.20.1
Weld Acc: ANSI B 16.11
Inspection standard: API598/DIN12266
Materials: CF8M (SS316), CF8 (SS304)
DIN 1.4408, SCS 14, WCB 1.0619 Available
Features:
Investment casting body
Working pressure 800/1000 psi for W.O.G.
Adjustable stem packing
Pressure Balance Hole In Ball Slot
Pure Teflon seals and seats
Temperature range: -60 to 450 °F
Blow-out proof stem, ball are made of ss316 or customer request
100% leakage tested at 100 psi air under water
Hydrostatic test pressure: 1500psi/3000psi
Locking device (option)
Others:
Design Standard: GB/T12224, GB/T8464
Pressure- Temperature Rating: GB/T12224
Face to Face Std: GB/15188.3
End Connection Std: G, Rc, Rp, NPT, BSP, BSPT, DIN259/299
Test Standard: GB/T13927
Material: WCB, CF8(304), CF8M(316)
Operated Way: Handle
Working Pressure: 2000WOG
