| Prod Model: |
D341F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Standard Or Nonstandard: |
Standard |
| Size: |
50-600 |
| Certificate: |
ISO9001, CE, RoHS |
| Delivery Time: |
in 45days |
| Connection Form: |
Flange |
| Work Pressure: |
Mid-Pressure (',2.5mpa< Pn <6.4mpa) |
| Structure: |
Double-Eccentric Sealing |
| Seal Form: |
Force Sealed |
| Working Temperature: |
Medium Temperature (',120??C
|
| Application: |
Household Usage |
| Material Of Seal Surface: |
Soft Sealed |
Product Description
Advantage:
1. OEM Factory : Professional manufacturer, clients from whole world.
2. High Quality, Competitive Price: Custom is accepted.
3. Complete Service: Long service Life, Fast delivery, Multilingual services.
4. Certificates: ISO9001, CE, TS, WRAS.
5. Low MOQ: Ready for providing the sample and producing some small orders.
Specification:
Technical Date
Material Specification
Nominal Diameter
DN50-DN600
Valve Body
Cast Iron or Ductile Iron
Nominal Pressure
PN10/PN16
Valve Disc
Ductile Iron or Stainless Steel
Operation Temperature
-40°C~225°C
Hand Bar or Hand Wheel
Cast Iron or Aluminium or Carbon Steel or Malleable S teel
Flange Driling Standard
EN 1902-2 PN10/16
Seal Material
EPDM OR NBR
Suface Treatment
Painting
Stem
Carbon Steel or Ductile Iron or Stainless Steel
Application
Portable water, water distribution service & feed lines, sewage disposol, irrigation, fire protection pipe systerm, etc.
