Low Pressure Liquid Oxygen Storage Tank
| Price: |
US $ 100-100000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
30m3, 60m3 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Geometric Volume: |
30,60 M3 |
| Medium: |
LNG |
| Working Temperature: |
-162 Centigrade |
| Main Material: |
06cr19ni10 |
| Storage Medium: |
Moncombustible/Nontoxic |
| Pressure Level: |
Low Pressure (',0.1MPa≤p<1.6MPa) |
| Condition: |
New |
Product Description
LNG storage tank is a device for liquefied natural gas, which is very strictly for the insulation and sealing. Shell is made of Q345, and the liner is made of 0Cr18Ni9Ti, filled in the middle of the perlite, double-layer insulation by vacuum powder insulation or multi-layer winding insulation.
We can provide imported or domestic valves for the tank.
Heat-insulating method is Perlite/High vacuum multilayer insulation. | Project | Unit | Parameter |
| Inner case | Outer case |
| Max Pressure | MPa | 1.2 | -0.1 |
| Geometric Volume | M3 | 30, 60 |
| Heat-insulating method |
| Perlite/High vacuum multilayer insulation |
| Structure form |
| Horizontal/Vertical |
| Medium |
| LNG |
| Sealing-off vacuum degree | Pa | <3 |
| Class |
| II |
| Design temperature | ºC | -196 | 60 |
| Working temperature | ºC | -162 | Ambient temperature |
| Filling rate | % | 90% |
| Static evaporation rate | %/d | <0.2 |
| Leak-out gassing rate | Pa. M3/s | <6x10-5 |
| Main material | Head |
| 06Cr19Ni10 | Q345R |
| Shell |
| 06Cr19Ni10 | Q345R |
| Welding coefficient |
| 1 | 0.85 |
Qingdao Luke Auto Gas Development Co., Ltd is a company established in 1997, located in the beautiful coastal city of Qingdao, as a China-Austria joint venture with the aim to protect our common environment. We are specializing in the manufacturing of Hydraulic piston CNG Compressors with big capacity, Automotive converting, Researching, Manufacturing, Installations and after-sale service for LNG refueling stations and CNG filling stations. At present, the company owns 10000 square meters manufacturing plant.
The company co-operates with foreign enterprises to develop the CNG gas stations and Skid-mounted LNG refueling station technology, suitable to the Chinese market. The products have obtained 14 national patents with advantages of lower costs, short time installation, usage of small area and high automatization.
Since the products have been launched to the market, they obtained warmly response from customers. Many filling stations have been installed all over the country, at present we maintain 10% market share in China.
After many years of development, we have rich experiences in production, installations and after- sale service in the industry. At present, we have build up four centers in China, such as Qingdao, Zhengzhou, Nanjing and Changchun city.
Based on high-quality products and excellent service, the company has good reputations and maintains close business relationship with famous domestic enterprises such as SINOPEC, PETRO China and CNOOC etc.
Our future development plan is to become a comprehensive group, committed to the new energy equipment design and manufacturing, professional installation, gas station management and international trade in natural gas fields.
