Low Temperature Floating Ball Valve
| Price: |
US $ 30/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal |
| Prod Model: |
1 piece body |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 300lb: |
2" |
| Connection Form: |
Flange |
| Channel: |
Tee Type |
| Structure: |
Floating Ball Valve |
| Type: |
Floating Ball Valve |
| Application: |
Household Usage |
| Material: |
Carbon Steel |
Product Description
PRODUCT RANGE
Class 150 from ½'' to 8''
Class 300 from ½'' to 8''
Class 600 from 1/2" to 4"
MATERIALS
BODY: Carbon steel, Stainless steel, Low temperature carbon steel, Duplex, Special Alloys,... Other materials under request
SOFT SEATS : PTFE, RPTFE, PEEK, DEVLON, NYLON,... Other materials under request
METAL SEAT:Tungsten Carbide(TC), Stellited
, Ni60...Other materials under request.
TRIM: A105+EP,304,316, 410, MONEL,... Other materials under request
DESIGN STANDARDS
ASME Standards:
B1.20.1Pipe Threads,General Purpose(Inch)
B16.10Face-to-Face and End-to-End Dimensions of Valves
B16.25Buttwelding Ends
B16.11Forged Fittings, Socket-Welding and Threaded
B16.5Flanged Fittings and Pipe Flanges
B16.47Large Diameter Steel Flanges
API Standards:
6DSpecifications for Pipeline valves
598Valve Inspection and Testing
607Fire test for soft-seated quarter-turn valves
6FASpecification for Fire Test for Valves
MSS Standards:
SP-55Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Visual Method for Evaluation of Surface Irregularities
SP-54Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Radiographic Examination Method
SP-53Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Magnetic Particle Examination Method
DESIGN FEATURE
Split body, full bore. Fire-Safe certified, floating ball, blow out proof stem, flanged connections.
Non-removable antistatic devices assure electric continuity between ball and body through the stem.
All wetted component materials and bolting meet NACE MR.01.75 latest edition as standard.
Cavity pressure relief hole avoids overpressure in the cavity with the valve in open position.
Asbestos free.
APPLICATION
Refinery
Chemical
Petrochemical
Power plant
Gas
FACTORY
Testing & Inspection
Finish products & valves on site service
TAIYI Valve Co., was founded in 2005, which is an industrial ball valve manufacturer of China, covering trunnion mounted, floating, top entry, DBB and metal seat type ball valves etc. In carbon steel & stainless steel materials and used in oil & gas, chemical, water field and etc. With ISO 9001 certified.
TAIYI Co., now has our own manufacturing facility with more than 5, 000 square feet locating in qianshi industrial zone, Owned with modern production facility and technical skills with annual output of 10million tons, which above 70% sold to overseas, such as Middle East, Europe, Southeast Asia, South America etc.
TAIYI Co., always regards product's quality and client's requirements as our central work. Through years of consistent innovation and development, we got good reputation from our esteemed clients with timely delivery, good quality and best services.
We will be your choice for ball valve!
TAIYI Valve Co., was founded in 2005, which is an industrial ball valve manufacturer of China, covering trunnion mounted, floating, top entry, DBB and metal seat type ball valves etc. In carbon steel & stainless steel materials and used in oil & gas, chemical, water field and etc. With ISO 9001 certified.
TAIYI Co., now has our own manufacturing facility with more than 5, 000 square feet locating in qianshi industrial zone, Owned with modern production facility and technical skills with annual output of 10million tons, which above 70% sold to overseas, such as Middle East, Europe, Southeast Asia, South America etc.
TAIYI Co., always regards product's quality and client's requirements as our central work. Through years of consistent innovation and development, we got good reputation from our esteemed clients with timely delivery, good quality and best services.
We will be your choice for ball valve!
