Slp Series 2 Way General Purpose Diaphragm Brass Solenoid Valve
| Price: |
US $ 6.50/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
5/Piece |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
SLP |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Port Size: |
1/8 to 2" |
| Seal Material: |
NBR, Viton |
| Working Pressure: |
0.05 to 16bar |
| Type: |
Pilot Operated |
| Connection Form: |
Thread |
| Valve Structure: |
Pilot Piston Structure |
| Power Supply: |
AC Solenoid Valve |
| Application: |
Water Industrial Usage |
Product Description
SLP series valves are the most famous 2/2 solenoid valve in our products list. The working pressure can reach 1.3MPa.Normal close and normal open is optional. The port size ranges from 1/8"to2". It can be used in many different medium like air, gas, oil etc. Excellent performance and widely application settle the position in solenoid valves. The annual output is around 720,000pcs.
Characteristic:
1. Pilot operated diaphragm construction with lower power
Consumption for longtime working
2. Applied to pressure system opened from 0.3 bars;
3. Lifespan can be at 1 million cycles.
Medium: Water, Air, Oil, Natural gas, Hot water.
Temperature: NBR: -10 ~ 80
VITON: -10 ~ 120
Pressure: 0.05 ~ 1.60MPa
Body: Brass Or Stainless Steel SUS304
Port Size: 3/8\1/2\3/4\1\11/4\11/2\2
Orifice (mm): DN 15\20\25\32\40\50f
Voltage: DC: 12V, 24V\36V
AC: 220/230V, 110/120V, 24V (50/60Hz)
|
Model |
SLP-06 |
SLP-08 |
SLP-10 |
SLP-15 |
SLP-20 |
SLP-25 |
SLP-35 |
SLP-40 |
SLP-50 |
|
SLP-06S |
SLP-08S |
SLP-10S |
SLP-15S |
SLP-20S |
SLP-25S |
SLP-35S |
SLP-40S |
SLP-50S |
|
Working Medium |
AIR,GAS,WATER,HOT WATER,LIQUID |
|
Type |
2/2 Normal Open |
|
Flow rate(mm) |
3 |
3 |
10 |
13 |
20 |
25 |
35 |
45 |
50 |
|
Cv |
0.23 |
0.23 |
4.5 |
4.5 |
7.6 |
12 |
22 |
30 |
48 |
|
Joint Size |
1/8" |
1/4" |
3/8" |
1/2" |
3/4" |
1" |
1-1/4" |
1-1/2" |
2" |
|
Working Pressure |
0-16Bar |
0.5-16Bar |
|
Max.pressure Resistance |
17Bar |
|
NOTE |
SEAL MATERIAL:NBR/EPDM/VITON |
|
ENVIRONMENT TEMPERATURE:0-65 |
|
MAX,TEMPERATURE FOR MEDIA:NBR:80 EPDM/VITON:120 |
|
VALVE BODY:SLP:BRASS SLP-S1:SS316 |
Location and History
Regis' Manufacturing plant is located in Ningbo city, Zhejiang Province. Our factory was built in the spring of 1999 by Mr. Jason Yuan. After 15 years development, Regis has already grown up from just a hardware producer to a modern and famed pneumatic manufacturer in China.
A Wide Range of Products and Services
Its current catalogue of standard products includes more than 1, 000 items including air cylinders, solenoid valves, air source treatments, couplings, connectors and other related accessories, all of them designed to meet industrial needs in handling all kinds of gases and liquids such as water, air, steam, oils refrigerants, oxygen, liquid nitrogen, corrosive products, among others. Laboratories, petroleum, engineering, building, food and beverage, refrigeration, heating, automobile, metallurgical, textile and petrochemical are some of the industries that testify to the quality of each of Regis' Products.
Achievement and Honor
Regis ' Sales performance has exceeded 20 million us dollars in 2010. We have been awarded the medal of the quickest developing automation industry by government.
The excellence of all our products, proven by several national and international standards and quality control boards, is guaranteed by the total quality program enforced throughout the company.
They function with high tech machines and production tools as well as computerized production management system. All steps in a product development, from design onto testing, production, logistics, and finally delivery, are regularly subject to rigorous quality controls.
Our Ambition
To be the best pneumatic manufacturer in China
Regis ' Products are spread into 98 Countries all over the world. Now our aim is to compete with the world first class in the next 10 years. We plan to set 800 sales distribution throughout the world which can tight knit network enables our customers to benefit from high accessibility and short delivery times. The supreme ambition is to strengthen the ability to give the best service possible
