Product Description
Operated way: Direct operated
Control way: Nc(standard), no
Pipe size: G1/8~g1/4(standard)
Dn: Dn1~4mm
Pn: The highest pn: 4.0mpa
Medium: Neutral gas and liquid
Viscosity: ≤ 21mm2/s
Medium temperature: -10~+80(+180 degree centigrade)
Circumstance temperature: -10~+50degree centigradematerial: Stainless steel
Sealing material: NBR(standard)\FPM\ptee
Standard voltage: AC: 220V(50/60Hz) DC: 24V
Changeable of the voltage: ± 10%
Working period: Coil can work continuously
Connecting: Junction box(plug), IP65
Installation: Head is up straight.
|
Standard: |
Item no.
(2/2WAY) |
DN
(mm) |
PIPE SIZE
(G) |
PN
(MPa) |
Kv
(m3/h) |
circumstance temperature |
medium temperature |
|
2231001Cr |
1 |
1/8~1/4 |
0~4.0 |
0.02 |
-10~+50 |
-10~+80 |
|
2231002Cr |
2 |
1/8~1/4 |
0~2.5 |
0.08 |
|
2231003Cr |
3 |
1/8~1/4 |
0~1.0 |
0.16 |
|
2231004Cr |
4 |
1/8~1/4 |
0~0.6 |
0.16 |
|
Standard: |
Item no.
(2/3WAY) |
DN
(mm) |
PIPE SIZE
(G) |
PN
(MPa) |
Kv
(m3/h) |
circumstance temperature |
medium temperature |
|
2331001Cr |
1.5 |
1/8~1/4 |
0~1.6 |
0.02 |
-10~+50 |
-10~+80 |
|
2331002Cr |
2 |
1/8~1/4 |
0~1.0 |
0.08 |
|
2331003Cr |
2.5 |
1/8~1/4 |
0~0.6 |
0.16 |
