| Prod Model: |
QF-35C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Standard Or Nonstandard: |
Standard |
| Power: |
Manual |
| Structure: |
Shutoff |
| Pressure: |
Medium Pressure |
| Temperature Of Media: |
Normal Temperature |
| Material: |
Outlet G1/2, Inlet Unf1.125-12 |
| Suitable Medium: |
CO2( Carbon Dioxide) |
| Loading Port: |
Shanghai Port |
| Delivery Time: |
Within 16 Days |
Product Description
Medium Pressure QF-35C Brass Carbon Dioxide Cylinder Valve
In our company we can product 15 types of CO2 cylinder valve for you and the product list in the below:
1: QF-2A 2: QF-2A1 3: QF-2A8 4: QF-2A17 5: QF-17 6: QF-16A 7: QF-35 8: QF-35A 9: QF-35B 10: QF-35C 11: F-5 12: F-2M 13: F-2M1 14: F-2M2 15: F-2N
Specification
1)Suitable Medium: CO2
2)Working Pressure: 15Mpa
3)Nominal diameter: DN4mm
4)Outlet thread: G1/2
5)Inlet thread(joint to cylinder): UNF1.125-12
6)Safety device: 21± 1.5Mpa
Packaging & Delivery
Packaging Details: 25 sets/carton
Delivery Detail: Within 20days
Quality certificate
SQC certificate for quality management system, has complied with the requirements of GB/T 19001-2000 idt ISO 9001: 2000
Manufacture License of Special equipment in People's Republic of China TSF210024-2012
|
NO. |
Type No. |
Produce Name |
suitable
Medium |
PN
(Mpa) |
DN
(mm) |
Outlet thread(mm) |
Jiont Thread
to cylinder (mm) |
Temp./Pressure
of safety device |
|
1 |
QF-2A |
Brass Shaft Coupling type Cylinder valve for CO2 |
CO2 |
15 |
7 |
G5/8 |
GB8335 PZ27.8 |
21±1.5 |
|
2 |
QF-2A1 |
Brass Shaft Coupling type Cylinder valve for CO2 |
CO2 |
15 |
7 |
W22 x 1/14 |
GB8335 PZ27.8 |
21±1.5 |
|
3 |
QF-2A8 |
Brass Shaft Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
W21.8 x 1/14 |
GB8335 PZ27.8 |
21±1.5 |
|
4 |
QF-2A17 |
Brass Shaft Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
CGA320 |
GB8335 PZ27.8 |
21±1.5 |
|
5 |
QF-17 |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
12.5 |
4 |
CGA320 |
UNF1.125-12 |
15-18.75 |
|
6 |
QF-16A |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
2.5 |
W21.8 x 1/14 |
M18 x 1.5 |
21±1.5 |
|
7 |
QF-35 |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
CGA320 |
UNF1.125-12 |
21±1.5 |
|
8 |
QF-35A |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
W22 x 1/14 |
UNF1.125-12 |
21±1.5 |
|
9 |
QF-35B |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
W22 x 1/14 |
UNT(1A)3/4-16 |
21±1.5 |
|
10 |
QF-35C |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
G1/2 |
UNF1.125-12 |
21±1.5 |
|
11 |
F-5 |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
7 |
Female Thread G5/8 |
GB8335 PZ27.8 |
21±1.5 |
|
12 |
F-2M |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
W22 x 1/14 |
JIS B 8246 V2 |
21±1.5 |
|
13 |
F-2M1 |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
W22 x 1/14 |
GB8335 PZ27.8 |
21±1.5 |
|
14 |
F-2M2 |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
W22 x 1/14 |
GB8335 PZ19.2 |
21±1.5 |
|
15 |
F-2N |
Brass Flapper Coupling type Cylinder valve for CO2 |
CO2 |
15 |
4 |
W21.8 x 1/14 |
JIS B 8246 V2 28 |
21±1.5 |
We Nanjing Greteq Industrial Co., Ltd have a long history in China. Now we have two mainly products: Ductile iron pipe/fittings and gas cylinder valve/gas equipment.
In ductile iron pipe/fitting department we use the lost-foam casting process and resin bonded sand process and make production and inspection strict according to ISO2531, BSEN545, BSEN598 and GB/T13295 standard. It annually produces 200000 tons of ductile iron pipe and 15000 tons pipe fitting The diameter are from 80-2600. We have a owned ductile iron pipe factory and several cooperative iron pipe and fitting factory, So we can meet your big quantity order and supply all diameter size ductile ion pipe and fitting to you in short times. Our goods are only for export and had succeeded exported to America, Europe, Africa, Oceania, Southeast Asia and the Middle East.
In gas cylinder valve/gas equipment department. The mainly products are including high and middle pressure oxygen/acetylene/CO2/H2/N2/Ar/Cl/Freon cylinder valve, CGA cylinder valve, CNG/LNG cylinder valve, cryogenic valvepipe shutoff valve and pressure reducer used for all kindly of industries, SCBA cylinder valve and so on. Those products are well-known in domestic market and exported in many countries.
We will 'Survival by Quality, Development by Credit' and looking for your inquiry.
